2-inch Digital Attitude Indicator | Mid-Continent Instruments and Avionics

JavaScript seems to be disabled in your browser. For the best experience on our site, be sure to turn on Javascript in your browser.

Benefits and Specifications

Four Primary Functions	Attitude, slip, turn rate and heading Utilize modern solid-state MEMS gyro and accelerometer
ARINC	Heading with primary avionics via external ARINC input
Easy Installation	User-selectable panel tilt and roll-offset
Size	Fits standard 2-inch panel cutout
Battery	Rechargeable, field-replaceable emergency battery (available)
Lightweight	Weighs just 0.4 lbs
Simple user interface	Single, push-and-turn control knob
Display	Daylight readable LCD and smooth, high-resolution graphics
Lighting	Manual, external lighting control or built-in photocell for automatic dimming
Night Vision Imaging System (NVIS)	NVIS compatible units (available)
Certified	TSO certified (Design Assurance Level A)
Made in the USA	Designed and built in Wichita, Kansas, USA
Warranty	Two-year limited warranty

Power Input	10–32 VDC 0.14A @ 28 VDC; 4 watts nominal
Data Input	ARINC 429: Low or high speed; Label 320
Data Output	ARINC 429: Low or high speed; Labels 320, 324, 325
Operating Range	360° angle, 500° per second for pitch and roll (maximum)
Lighting	5, 14, or 28 VDC external control or internal photocell for automatic dimming
Battery	Rechargeable, field-replaceable emergency battery supply (available) P/N 6430006-(1) Technology: Nickel-Metal Hydride (NiMH) Attributes: 0.25A @ 24 VDC nominal (6 Wh capacity) Runtime: 60 minutes @ 0.25A
Weight	0.4 lbs (0.17 kg)
Mounting	Rear panel mounted, (4) #6–32 screws, 2.25-inch round bezel
Dimensions	2.43 x 2.43 x 1.0 inches (61.7 x 61.7 x 25.4 millimeters)
Mating Connector	P/N 9019162-1: 26-pin, D-Sub electrical connector (Quick Disconnect)
Certification	FAA TSO certified to C3e, C4c, C8e, C10c, C106, C113b, C201 RTCA DO-160G qualified RTCA DO-178C qualified, Design Assurance Level (DAL) A
Rights	U.S. Patent 11,048,389

Digital Attitude Indicator Supplemental Type Certificates (STCs)

Select your aircraft manufacturer from the dropdown menu to view a list of applicable STCs.

Manufacturer: Aerostar

STC Number	Aircraft Model
SA02010WI	PA-60-600 PA-60-601 PA-60-601P PA-60-602P PA-60-700P

Manufacturer: Beechcraft

STC Number	Aircraft Model
SA02010WI	B-95A D-95A E95 95-55 95-A55 95-B55 95-B55A 95-B55B (T-42) 95-C55 95-C55A D55 D55A E55 E55A 56TC A56TC 58 58A G58 95 B95
SA02010WI	65 (L-23F) A65 A-65-8200 65-80 65-A80 65-A80-8800 65-B80 65-88 65-90 65-A90 65-A90-1 (JU-21A) 65-A90-1 (U-21A) 65-A90-1 (RU-21A) 65-A90-1 (RU-21D) 65-A90-1 (U-21G) 65-A90-1 (RU-21H) 65-A90-2 (RU-21B) 65-A90-3 (RU-21C) 65-A90-4 (RU-21E) 65-A90-4 (RU-21H) 70 C90 C90A C90GT C90GTi B90 E90 H90 (T-44A)
SA02010WI	T-34 Series: (TC 5A3) (45(YT-34) A45 (T-34A, B-45) D45 (T-34B)
SA02010WI	390
SA02010WI	99 99A 99A (FACH) A99 A99A B99 C99 100 A100 (U-21F) B100
SA02010WI	58P 58PA 58TC 58TCA
SA02010WI	200 200C B200 B200C B200T B200CT B200GT 1900 1900C 1900C (C-12J) 1900D 300 300LW B300 B300C B300C (MC-12W) B300C (UC-12W)
SA02010WI	F90

Manufacturer: Cessna

STC Number	Aircraft Model
SA02010WI	310 310A (USAF U-3A) 310B 310C 310D 310E (USAF U-3B) 310F 310G 310H E310H 310I 310J 310J-1 E310J 310K 310L 310N 310P T310P 310Q T310Q 310R T310R
SA02010WI	320/335/340 Series: 320 320-1 320A 320B 320C 320D 320E 320F 335 340 340A
SA02010WI	LC40/41/42/T240 (Lancair/Columbia/Corvallis) (LC40-550FG, LC41-550FG, LC42-550FG, T240)
SA02010WI	510
SA02010WI	Citation 525 Series: 525 525A 525B 525C
SA02010WI	501 551
SA02010WI	441
SA02010WI	208 208B
SA02010WI	401 401A 401B 402 402A 402B 402C 411 411A 414 414A 421 421A 421B 421C 425

Manufacturer: Dornier Luftfahrt GmbH

STC Number	Aircraft Model
SA02010WI	Do 28D Do 28D-1 Dornier 228-100 Dornier 228-101 Dornier 228-200 Dornier 228-201 Dornier 228-202 Dornier 228-212

Manufacturer: Learjet Inc. (Bombardier Inc.)

STC Number	Aircraft Model
ST01138DE	24 24A 24B 24B-A 24C 24D 24E 24F 24F-A 25 25A 25B 25C 25D 25F 31 31A 35 35A (C-21A) 36 36A 55 55B 55C 60

Manufacturer: Mitsubishi

STC Number	Aircraft Model
SA02010WI	MU-2B-25 MU-2B-26 MU-2B-26A MU-2B-35 MU-2B-36 MU-2B-36A MU-2B-40 MU-2B-60
SA02010WI	MU-2B MU-2B-10 MU-2B-15 MU-2B-20 MU-2B-25 MU-2B-26 MU-2B-30 MU-2B-35 MU2B-36

Manufacturer: Pilatus

STC Number	Aircraft Model
SA02010WI	PC-12 PC-12/45 PC-12/47 PC-12/47E

Manufacturer: Piper

STC Number	Aircraft Model
SA02010WI	PA-42 PA-42-720 PA-42-1000
SA02010WI	PA-46-310P PA-46-350P PA-46R-350T PA-46-500TP PA-46-600TP
SA02010WI	PA-42-720R

Manufacturer: Twin Commander

STC Number	Aircraft Model
SA02010WI	690 690A 690B 690C 690D 695 695A 695B
SA02010WI	500 500A 500B 500U 520 560 560A 560E 500S
SA02010WI	700

Manufacturer: Viking Air

STC Number	Aircraft Model
SA02010WI	DHC-6-1 DHC-6-100 DHC-6-200 DHC-6-300 DHC-6-400
