2-inch Digital Airspeed Indicator | Mid-Continent Instruments and Avionics

JavaScript seems to be disabled in your browser. For the best experience on our site, be sure to turn on Javascript in your browser.

Benefits and Specifications

Configurable	Configurable range up to 500 knots (or MPH), range markings and dynamic MMO barber pole indicator
Selectable Mach Number Display	User-selectable Mach number display ON/OFF
Ground Speed and True Air Speed	Ground Speed and True Air Speed indication via ARINC 429
Size	Fits standard 2-inch panel cutout
Battery	Rechargeable, field-replaceable emergency battery (available)
Lightweight	Weighs just 0.4 lbs
Simple user interface	Single, push-and-turn control knob
Display	Daylight readable LCD and smooth, high-resolution graphics
Lighting	Manual, external lighting control or built-in photocell for automatic dimming
Night Vision Imaging System (NVIS)	NVIS compatible units (available)
Certified	TSO certified (Design Assurance Level A)
Made in the USA	Designed and built in Wichita, Kansas, USA
Warranty	Two-year limited warranty

Power Input	10–32 VDC 0.14A @ 28 VDC; 4 watts nominal
Data Input	ARINC 429: Low or high speed; Labels 210, 312 Pressure: Absolute/static and differential/pitot (Quick Disconnect)
Data Output	ARINC 429: High speed; Labels 205, 206
Operating Range	Configurable range of 160, 200, 300, 400 or 500 knots
Units of Measure	Knots or miles per hour (MPH)
Lighting	Manual external lighting control or built-in photocell for automatic dimming
Battery	Rechargeable, field-replaceable emergency battery supply (available) P/N 6430006-(1) Technology: Nickel-Metal Hydride (NiMH) Attributes: 0.25A @ 24 VDC nominal (6 Wh capacity) Runtime: 60 minutes @ 0.25A
Weight	0.4 lbs (0.17 kg)
Mounting	Rear panel mounted, (4) #6–32 screws, 2.25-inch round bezel
Dimensions	2.43 x 2.43 x 1.0 inches (61.7 x 61.7 x 25.4 millimeters)
Mating Connector	P/N 9019162-1: 26-pin, D-Sub electrical connector (Quick Disconnect) P/N 9019162-2: Pneumatic fittings (Quick Disconnect)
Certification	FAA TSO certified to C2d, C106, C113b RTCA DO-160G qualified RTCA DO-178C qualified, Design Assurance Level (DAL) A
Rights	U.S. Patent 11,048,389

Digital Airspeed Indicator Supplemental Type Certificates (STCs)

Select your aircraft manufacturer from the dropdown menu to view a list of applicable STCs.

Manufacturer: Aerostar

Aircraft TC	Aircraft Model
A17WE	PA-60-600 PA-60-601 PA-60-601P PA-60-602P PA-60-700P

Manufacturer: Beechcraft

Aircraft TC	Aircraft Model
3A16	B-95A D-95A E95 95-55 95-A55 95-B55 95-B55A 95-B55B (T-42) 95-C55 95-C55A D55 D55A E55 E55A 56TC A56TC 58 58A G58 95 B95
3A20	65 (L-23F) A65 A-65-8200 65-80 65-A80 65-A80-8800 65-B80 65-88 65-90 65-A90 65-A90-1 (JU-21A) 65-A90-1 (U-21A) 65-A90-1 (RU-21A) 65-A90-1 (RU-21D) 65-A90-1 (U-21G) 65-A90-1 (RU-21H) 65-A90-2 (RU-21B) 65-A90-3 (RU-21C) 65-A90-4 (RU-21E) 65-A90-4 (RU-21H) 70 C90 C90A C90GT C90GTi B90 E90 H90 (T-44A)
5A3	T-34 Series: (TC 5A3) (45(YT-34) A45 (T-34A, B-45) D45 (T-34B)
A00010W	390
A14CE	99 99A 99A (FACH) A99 A99A B99 C99 100 A100 (U-21F) B100
A23CE	58P 58PA 58TC 58TCA
A24CE	200 200C B200 B200C B200T B200CT B200GT 1900 1900C 1900C (C-12J) 1900D 300 300LW B300 B300C B300C (MC-12W) B300C (UC-12W)
A31CE	F90

Manufacturer: Cessna

Aircraft TC	Aircraft Model
3A10	200 200C B200 B200C B200T B200CT B200GT 1900 1900C 1900C (C-12J) 1900D 300 300LW B300 B300C B300C (MC-12W) B300C (UC-12W)
3A25	320/335/340 Series: 320 320-1 320A 320B 320C 320D 320E 320F 335 340 340A
A00003SE	LC40/41/42/T240 (Lancair/Columbia/Corvallis) (LC40-550FG, LC41-550FG, LC42-550FG, T240)
A00014WI	510
A1WI	Citation 525 Series: 525 525A 525B 525C
A27CE	501 551
A28CE	441
A37CE	208 208B
A7CE	401 401A 401B 402 402A 402B 402C 411 411A 414 414A 421 421A 421B 421C 425

Manufacturer: Dornier Luftfahrt GmbH

Aircraft TC	Aircraft Model
A16EU	Do 28D Do 28D-1 Dornier 228-100 Dornier 228-101 Dornier 228-200 Dornier 228-201 Dornier 228-202 Dornier 228-212

Manufacturer: Mitsubishi

Aircraft TC	Aircraft Model
A10SW	MU-2B-25 MU-2B-26 MU-2B-26A MU-2B-35 MU-2B-36 MU-2B-36A MU-2B-40 MU-2B-60
A2PC	MU-2B MU-2B-10 MU-2B-15 MU-2B-20 MU-2B-25 MU-2B-26 MU-2B-30 MU-2B-35 MU2B-36

Manufacturer: Pilatus

Aircraft TC	Aircraft Model
A78EU	PC-12 PC-12/45 PC-12/47 PC-12/47E

Manufacturer: Piper

Aircraft TC	Aircraft Model
A23SO	PA-42 PA-42-720 PA-42-1000
A25SO	PA-46-310P PA-46-350P PA-46R-350T PA-46-500TP PA-46-600TP
A32SO	PA-42-720R

Manufacturer: Twin Commander

Aircraft TC	Aircraft Model
2A4	690 690A 690B 690C 690D 695 695A 695B
6A1	500 500A 500B 500U 520 560 560A 560E 500S
A12SW	700

Manufacturer: Viking Air

Aircraft TC	Aircraft Model
A9EA	DHC-6-1 DHC-6-100 DHC-6-200 DHC-6-300 DHC-6-400

MD23-225 Resources

Product Fliers and Brochures

Technical Documents

Installation Manual

Technical Drawing

Service Notifications

FAA Approved Model List (AML)

AML STC SA02010WI
