DC-to-DC Voltage Converter
Are you a pilot or aircraft owner? Search our Dealer Locator to find our products near you.
The TC230 aircraft voltage converter supplies 230 watts of power from your aircraft’s exiting 10 – 18 VDC input to power 28 VDC equipment. The 6430234-2 converter is available with a remote on/off feature and is FAA TSO certified.
- Supplies 230 watts of 28-volt power to electronic equipment, including lighting and cabin accessories
- Lightweight — 0.70 lbs
- 230 watts output power
- 90% efficiency
- Input Voltage: 10 – 18 VDC
- Input Current: 18.0 A Nominal
- Output Voltage: 28 VDC
- Input transient, overload and short circuit protection, temperature monitoring, reverse polarity
- Rated from -67°F to +158°F (-55°C to +70°C)
- Remote On/Off (included)
- Mating Connector: P/N 9018655
- FAA TSO C71 certified and RTCA DO-160G qualified
- Designed and built in Wichita, Kansas, USA
- Two-year limited warranty
Input Voltage
10 – 18 VDC
Input Current
18.0 A Nominal
Output Voltage
28 VDC
Output Power
230 watts
Efficiency
90%
Weight
0.70 lbs (0.32 kg)
Altitude
55,000 ft
Temperature
-67°F to +158°F (-55°C to +70°C)
Protection
Input transient, overload and short circuit protection, temperature monitoring, reverse polarity
Remote Control
Remote On/Off Included
Mating Connector
P/N 9018655
Case
Anodized aluminum, blue
Certification
FAA TSO C71 certified
RTCA DO-160G qualified
